What is the difference between light, medium and heavy class MS pipe?

The three classes denote progressively thicker wall thickness for the same nominal bore. Light class is used for low-pressure water and conduit; medium class for general plumbing; heavy class for fire mains and higher-pressure service.

Are MS pipes available galvanised?

Yes: hot-dip galvanised MS pipes (also called GI pipes) are standard for outdoor and plumbing service. Available in light, medium and heavy classes.

Transcontinental Indenting Co.

Dubai · Since 1974

EST. 1974Contact punit@ticdubai.ae

Englishالعربية

Pipes & Hollow Sections · General-purpose MS pipe

MS Pipes

Mild steel pipes for water, structural and general use

Mild Steel (MS) pipes are general-purpose welded steel pipes manufactured to IS 1239, BS 1387, ASTM A53 and equivalent standards. Supplied in light, medium and heavy classes, they are used for water lines, plumbing, structural posts, scaffolding and general fabrication.

Light / medium / heavy classes

Plumbing & water lines

Galvanised standard

Threaded & socketed

Request Quote WhatsApp Email Spec

Standards

IS 1239, BS 1387, ASTM A53

Classes

Light (yellow), Medium (blue), Heavy (red)

NB range

15 – 150 mm (1/2" – 6")

Length

6 m

Finish

Black / galvanised

End

Plain / threaded & socketed

Quick reference

MS Pipes: the essentials.

A concise, citation-ready summary used by search engines, AI assistants and procurement teams to answer common questions about ms pipes.

MS Pipes are hot-rolled structural steel sections supplied by TIC Dubai across the UAE and GCC.
Standards: IS 1239, BS 1387, ASTM A53.
Classes: Light (yellow), Medium (blue), Heavy (red).
NB range: 15 – 150 mm (1/2" – 6").
Length: 6 m.
Applications include plumbing & water lines, fire-fighting systems, structural posts & fences.

Industry applications

Plumbing and water distribution, fire-fighting lines, structural posts, fence posts, scaffolding tubes, agricultural irrigation and general fabrication.

Specifications

MS Pipes: full technical data.

Indicative mill data. Customised grades, sizes and certifications available on request.

Property	Value
Standards	IS 1239 Part 1, BS 1387, ASTM A53 Gr.A/B
Classes	Light (yellow band), Medium (blue band), Heavy (red band)
Nominal Bore	15, 20, 25, 32, 40, 50, 65, 80, 100, 125, 150 mm
Lengths	6 m standard
End	Plain or threaded & socketed (T&C)
Coating	Black or hot-dip galvanised (G.I.)

Swipe to view more

Visual profile

Engineering cross-section.

Reference cross-section diagram showing the principal dimensions used in structural specification. Detailed dimension tables, weight per metre and section properties are available in our full data sheet. Share your project requirement and we'll send a tailored specification pack.

Request data sheet

Applications

Where MS Pipes is specified.

Plumbing & water lines
Fire-fighting systems
Structural posts & fences
Scaffolding tubes
Agricultural irrigation
General fabrication

Why TIC Dubai

Mill-direct supply, GCC project expertise.

Global mill-direct sourcing

Direct relationships with primary mills in China, India, Türkiye, Korea, Japan, Vietnam, the GCC and Europe, with competitive ex-mill pricing and verified origin.
