Profile & applications
Stainless tees combine a flange and stem in one rolled or fused section. Used as architectural exposed lintels, balustrade tops, modular framing components and food-grade equipment frames.
Cross-section · T-Section
Stainless Steel Structural Profiles · Stainless T-section
Stainless Steel Tees
T-section stainless beams for framing & decorative use
Stainless tees (T-sections) are hot-rolled or laser-fused profiles with a flange and a perpendicular stem. Used in stainless for lintels, splice plates, edge trims, architectural framing, balustrade tops and modular framing components.
T-section profile
Hot-rolled or laser-fused
Austenitic & duplex grades
Architectural & process applications
Standards
EN 10055, ASTM A276, EN 10088-4
Grades
304, 304L, 316, 316L, Duplex 2205
Flange × stem
30×30 – 150×150 mm
Thickness
3 – 15 mm
Finish
2B / satin / mirror
Lengths
6 / 12 m
Quick reference
Stainless Steel Tees: the essentials.
A concise, citation-ready summary for engineers, architects, AI assistants and procurement teams.
- Stainless Steel Tees are supplied by TIC Dubai across the UAE, GCC and wider Middle East in austenitic, ferritic and duplex stainless grades.
- Standards: EN 10055, ASTM A276, EN 10088-4.
- Grades: 304, 304L, 316, 316L, Duplex 2205.
- Flange × stem: 30×30 – 150×150 mm.
- Thickness: 3 – 15 mm.
- Applications include architectural lintels, balustrade tops, modular framing.
Specifications
Stainless Steel Tees: full technical data.
| Property | Value |
|---|---|
| Designation | 30×30×3 to 150×150×15 |
| Standards | EN 10055 / ASTM A276 / EN 10088-4 |
| Grades | 1.4301 / 1.4307 / 1.4401 / 1.4404 / 1.4462 |
| Standard lengths | 6, 12 m |
Swipe to view more
Applications
Where stainless steel tees are specified.
Architectural lintels
Balustrade tops
Modular framing
Food-grade equipment frames
Splice plates
