Applications
Stainless secondary beams, façade backing structures, retail and joinery framing, decorative ceiling structures, food-grade plant frames and balustrade horizontals.
Cross-section · Rectangular Hollow Section
Stainless Steel Pipes & Tubes · Stainless rectangular hollow section
Stainless Steel Rectangular Tubes
Stainless rectangular hollow sections for architectural framing
Stainless rectangular hollow sections (RHS) deliver asymmetric stiffness combined with stainless corrosion resistance and architectural finish, making them the default choice for stainless beams, façade backing structures, retail and decorative framing.
Asymmetric stiffness
Architectural finishes
Structural-rated
PVC film protected
Standards
ASTM A554 / A500, EN 10296-2 / 10297-2
Grades
304, 304L, 316, 316L
Size range
20 × 10 – 300 × 200 mm
Wall thickness
1 – 8 mm
Finish
No.4 / mirror / pickled
Lengths
6 / 12 m
Quick reference
Stainless Steel Rectangular Tubes: the essentials.
A concise, citation-ready summary for engineers, architects, AI assistants and procurement teams.
- Stainless Steel Rectangular Tubes are supplied by TIC Dubai across the UAE, GCC and wider Middle East in austenitic, ferritic and duplex stainless grades.
- Standards: ASTM A554 / A500, EN 10296-2 / 10297-2.
- Grades: 304, 304L, 316, 316L.
- Size range: 20 × 10 – 300 × 200 mm.
- Wall thickness: 1 – 8 mm.
- Applications include architectural secondary beams, façade backing structures, retail & joinery framing.
Specifications
Stainless Steel Rectangular Tubes: full technical data.
| Property | Value |
|---|---|
| Standards | ASTM A554 / A500, EN 10296-2 / 10297-2 |
| Grades | 1.4301 / 1.4307 / 1.4401 / 1.4404 |
| Size (a × b) | 20 × 10 to 300 × 200 mm |
| Wall thickness | 1 – 8 mm |
| Lengths | 6, 12 m or cut-to-length |
Swipe to view more
Applications
Where stainless steel rectangular tubes are specified.
Architectural secondary beams
Façade backing structures
Retail & joinery framing
Decorative ceilings
Food-grade equipment frames
Balustrade horizontals
